| Place of Origin: | Baoji，China |
|---|---|
| Brand Name: | HT SENSOR |
| Certification: | CE,RoHs,ISO9001 |
| Model Number: | BPZK01-1 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Standard Export Package |
| Delivery Time: | 5-8 work days |
| Payment Terms: | Western Union, L/C, T/T |
| Supply Ability: | 5000PCS/Month |
| Model NO.: | BPZK01-1 | Power: | 24VDC/220VAC |
|---|---|---|---|
| Contact Type: | Type C Contact | Output: | 4-20mA /0-20mA |
| Dia: | 100mm | Display: | LED |
| Transport Package: | Carton | Specification: | 10kpa~100mpa |
| Number Of Switch: | 2-4 Control Switch | Structure: | Amplifier Built-in Type |
| Usage: | Control Switch | Customization: | Available |
| High Light: | 0-10VDC Electronic Pressure Switch,Electronic Pressure Switch 16bar,16bar Digital Differential Pressure Switch |
||
Applications of Electronic Pressure Switch:
Measurement and control of fluid medium pressure/differential pressure in hydraulic, metallurgical, chemical and other industries for automatic control applications.
| Performance Parameters of Electronic Pressure Switch | |
| Measurement Range | -100kPa…0kPa ~ 10kPa…100MPa |
| 0-10KPa~2MPa(Differential Pressure) | |
| Pressure Type | Gauge Pressure, Absolute Pressure, Sealed Pressure,Differential Pressure |
| Overload | ≤ 1.5 times of the rated range |
| Accuracy @ 25ºC | ±0.25% (Typical) ±0.5% (Maximum) |
| Long-Term Stability | ±0.3%F.S/year |
| Zero Point Temperature Drift | ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa) |
| Full Scale Temperature Drift | ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa) |
| Compensation Temperature | 0-50ºC(0-10KPa, 0-20KPa) ,0-70ºC ,-10-70ºC |
| Operating Temperature | -20ºC~80ºC |
| Storage Temperature | -40ºC~120ºC |
| Housing Material | 1Cr18Ni9Ti |
| Diaphragm Material | 316L |
| Insulation Resistance | 100MΩ 100VDC |
| Relay Control | 1-4 channels of control or electronic switch quantity control |
| Contact Life | Exceeds 100,000 cycles |
| Display Range | -1999~9999 |
| Installation Method | vertical axis installation |
| Explosion-proof Rating | Intrinsically Safe |
| Protection Rating | IP65 |
| Weight | ~0.5kg |
| Output Signal | Supply Voltage | Output Type |
| 4~20mA / 0-20mA | 24VDC or 220VAC | 3 wire |
| 1-5VDC /0-5VDC | 24VDC or 220VAC | 3 wire |
| Ordering tips of Electronic Pressure Switch |
1. When selecting the product, please ensure that the measured medium is suitable for the contact part of the product.
2. Please indicate the power supply, accuracy level and number of control points when ordering.
3. The measuring range of the plate diaphragm pressure controller is 0~35KPa... 20MPa.
4. For users who choose differential pressure measurement, attention should be paid to the relationship between the differential pressure range and the allowed overpressure and maximum pressure of the high and low pressure chamber, and ensure that it meets the requirements of field applications. In order to ensure the safe and reliable operation of the product, it is recommended to install a three-valve manifold between the measuring point and the transmitter.
5. To ensure the reliable operation of the product, you are advised to install lightning protection devices on site and ensure that the product and power supply are grounded reliably. In case of strong vibration, instantaneous impact force, strong electromagnetic interference, RF interference and other special requirements, please inform our company and indicate in the order.
