| Range: | -100kPa...0kPa~20kPa...70MPa | Signal: | 24-bit High Accuracy Analog To Digital Convertor |
|---|---|---|---|
| OutPut Protocol: | I2C Interface Protocol | Temperature Compensated: | Real Time |
| Dimension: | Compact Size | Media: | Fluid And Gas |
| High Light: | i2c water pressure sensor,i2c differential pressure sensor |
||
Features:
Range: -100KPa.....0....20KPa......70MPa
n 24 Bit High precision analog to digital confversion
n Real time compensation
n Isolated structure for multiple media
n Output: 15-85%
n I2C interface protocol
Applications:
n Low power, smart device
n Process control
n Construction machinery
n Medicine, food processing, packaging equipment
Outline structure(unit:mm)
Range<20MP Range≥20MPa
Electrical Connection:
|
Item |
definition |
Wire color |
|
1 |
V+ |
Red |
|
2 |
V- |
Black |
|
3 |
SDA |
Yellow |
|
4 |
SCL |
Blue |
Specification:
|
Electrical characteristics |
|
|
Range |
0~100kPa……0~60MPa |
|
Overload |
1.5 times FS |
|
Accuracy |
±0.1%F.S. BFSL@25℃ |
|
Total error |
±1.0%F.S. (Includes calibration error and temperature drift effects) |
|
Input voltage |
1.8V~3.6VDC |
|
Output |
15%~85% (I 2 C Bus protocol) |
|
Working current |
≤0.3mA,Standby current is about 0.1μA |
|
Operating temperature |
-10℃~80℃ |
|
Storage temperature |
-40℃~125℃ |
|
Long-term stability |
±0.2%FS/year |
Output Conversion:
|
Percentage output(%) |
Digital quantity (decimal) |
Digital quantity (hexadecimal) |
|
0 |
0 |
0x000000 |
|
10 |
1677722 |
0x19999A |
|
15 |
2516582 |
0x266666 |
|
85 |
14260633 |
0xD99999 |
|
90 |
15099494 |
0xE66666 |
|
100 |
16777215 |
0xFFFFFF
|
