Product Details:
Payment & Shipping Terms:
|
| Measuring Range: | 0......40MPa.....100MPa | Pressure Type: | Piezoresistive |
|---|---|---|---|
| Output Signal: | 4~20mA/0.5-4.5VDC | Accuracy: | 0.5%/0.25% |
| Application: | Industrial M&C | Selling Units: | Single Item |
| Single Package Size : | 6X2.35X0 Cm | Single Gross Weight: | 0.300 Kg |
| Package Type: | Standar Export Packing By Carton | ||
| High Light: | liquid pressure transmitter,water pressure transmitter |
||
|
Pressure Parameter |
||
|
Range |
0.......10MPa.......100MPa |
|
|
Overload |
2 times Full Scale |
|
|
Pressure Type |
Gauge /Absolute/ Sealed Gauge |
|
|
Electric parameter |
||
|
Output Type |
Current |
Voltage |
|
Power supply |
9~30V DC |
5V DC |
|
Output signal |
4mA~20mA DC(2 wire) |
0.5~4.5VDC/0-5V DC (3-wire) |
|
Load resistance |
≤(U-9)/0.02Ω(2 wire) |
≥10k (3-wire) |
|
Construction parameter |
||
|
Housing |
Stainless steel |
|
|
Sensor |
Stainless steel 316L |
|
|
Sealed-ring |
Viton |
|
|
Protection class |
IP65 |
|
|
Ambient parameter |
||
|
Media applicability |
Fluid which has no corrosion to Stainless steel 316L and Viton |
|
|
Ambient temperature |
-10℃~80℃ |
|
|
Media temperature |
-30℃~80℃ |
|
|
Storage temperature |
-40℃~125℃ |
|
|
Performance index |
||
|
Accuracy |
≤±0.5%FS |
|
|
Zero temperature coefficient |
≤±0.02%FS/℃ |
|
|
Full temperature coefficient |
≤±0.02%FS/℃ |
|
|
Long term stability |
≤±0.3%FS/year (ma |
|
Xi’an Sensors Co., Ltd is a high-tech enterprise absorbed in providing customers with all kinds of pressure detection solution, design and produce pressure sensor. Our series of sensors have a wide range of applications including detection and automatic process control in transportation, energy, chemicals, shipbuilding, aviation, mechanical engineering, hydrology, medical and household appliances.
