| Range: | 0......350KPa......70MPa | Output: | 133+/-33 MV DC |
|---|---|---|---|
| Power Supply: | Max 2.0 MA DC | Response Time: | Max 1 Ms |
| High Light: | miniature pressure transducer,oil pressure sensor switch |
||
SMP 2000 series is an isolated oil - filled pressure sensor core with high performance, low cost and small size. It uses MEMS Silicon chip. Manufacturing of each sensor is a process with strict aging, screening and testing to ensure the excellent quality and high reliability. This product has high anti-overload capacity and wide temperature range, it is widely used in automobiles, loading machinery, pumps, air conditioning and other occasions where have high requirements on small size and cost-effective.
Features:
n Range:350kPa…70MPa
n Small Size:φ12.6mm, lower package cost
n SS 316L
n Isolated structure, for a variety of fluid medium pressure measurement.
Applications:
n Pressure measurement of automobile engine oil
nEngineering machinery, water pumps, equipment
nIndustrial process control
nUrban water supply system
Outline Construction:(Unit: mm)
<20MPa ≥20MPa
Specification:
|
Construction Condition |
|
|
Diaphragm material |
SS 316L |
|
Housing material |
SS 316L |
|
Pin Wire |
Kovar/100mm silicone rubber wire |
|
Back pressure tube |
SS 316L (gauge and negative pressure only) |
|
Seal ring |
Nitrile rubber |
|
Electrical Condition |
|
|
Power supply |
≤2.0mA DC |
|
Impedance input |
2.5kΩ~5 kΩ |
|
Impedance output |
2.5kΩ~5 kΩ |
|
Response |
(10%~90%):<1ms |
|
Insulation resistance |
100MΩ,100V DC |
|
Overpressure |
2 times FS |
|
Environmental Condition |
|
|
Media applicability |
Fluid which has no corrosion on stainless steel and nitrile rubber |
|
Shock |
No change at 10gRMS,(20~2000)Hz |
|
Impact |
100g,11ms |
|
Position |
Deviate 90° from any direction, zero change≤±0.05%FS |
|
Basic Condition |
|
|
Environment temperature |
(25±1)℃ |
|
Humidity |
(50%±10%)RH |
|
Atmospheric pressure |
(86~106) kPa |
|
Power supply |
(1.5±0.0015)mA DC |
