SMP3011 I2C output pressure sensor for water and oil

Features

• Ranges: -100kPa…0～20kPa┅70MPa
• 24-bit High precision analog to digital conversion
• Real-time compensation
• Isolated structure for multiple media
• Out put:15%~85%
• I²C Bus protocol
•
• Parameter

• Electrical characteristics
  Range	0～100kPa……0～70MPa
  Overload	1.5 times FS
  Accuracy	±0.1%F.S. BFSL@25℃
  Total error	±1.0%F.S. (Includes calibration error and temperature drift effects)
  Input voltage	1.8V～3.6VDC
  Output	15%~85% (I 2 C Bus protocol)
  Working current	≤0.3mA,Standby current is about 0.1μA
  Operating temperature	-10℃～80℃
  Storage temperature	-40℃～125℃
  Long-term stability	±0.2%FS/year
