Zigbee Wireless Pressure amp Temperature & Pressure Transmitter for Remote Environments
Product Description of Wireless Pressure & temperature transmitter:
The temperature and pressure integrated transmitter is an auxiliary product of the SZ series wireless monitoring system for oil and water wells, and is applicable to the pressure and temperature monitoring during the production, storage, and transportation of oil and water wells. It adopts a micro-power wireless communication mode, eliminating the need for wiring. The installation is quicker, safe, and convenient. There is also supporting wireless switching equipment that can convert multiple wireless pressure and temperature signals into ZIGBEE wireless standard signals through Ethernet transmission and can be easily integrated into the measurement and control system, having a wide range of applications.
Features of Wireless Pressure & temperature transmitter:
- Wireless test of pipeline pressure and temperature, typically used in oil wellhead pressure and temperature monitoring;
- explosion-proof design: flameproof aluminum shell, circuit board system intrinsically safe;
- Protection grade: IP65, fully sealed waterproof design;
- ZigBee communication, which can be configured and tested by hand copy;
- LCD display: -40~75℃ wide temperature range, can display pressure data, temperature data, battery voltage, wireless channel and other information;
- Adjustable installation direction: Connect to the onsite pipeline valve through a loose connector or adapter and adjust the direction.
- 38Ah high energy lithium sub-battery, long working life;
- high-gain antenna, wireless transmission distance of more than 90m;
- Temperature sensor head customized cable jacket to prevent cable connector breakage;
Applications of wireless pressure transmitter temperture transmitter:
- Compatible with stainless steel, non-corrosive liquids.
- Monitor temperature in various applications, such as water temperature.
- Industrial and municipal water, tanks, Wells, rivers, sea water,The temperature of lakes, etc.
Technical Parameters of Wireless Pressure & temperature transmitter:
| Measured Medium |
liquid/ gas |
| Pressure Range |
0~4MPa/ 0-150℃ other ranges can be customized |
| Accuracy |
0.5 level |
| Overload Pressure |
150% F.S |
| Reporting Cycle |
1 minute ~12 hours can be set |
| Decimal Places |
pressure display 2/temperature display 2 |
| Signal Transmission |
ZigBee wireless |
| Transmission Power |
≤40mW |
| Communication Distance |
≥90m |
| Working Power Supply |
3.6V lithium battery |
| Explosion-Proof Grade |
Ex ib IIB T3 Gb / IP65 |
| Process Interface |
pressure sensing head 1/2NPT customers can make. |
| Working Environment Temperature |
-40~75℃ |
| Working Environment Humidity |
≤ 97%RH |
| Product Weight |
2000g |
FAQ:
FAQ:
1. Q: What are the features of your pressure sensor transmitters?
A: Our pressure sensor transmitters are characterized by high precision, durability, and excellent performance, with the option for customization.
2. Q: Can I customize special specifications?
A: Yes, our engineers can tailor products to meet specific needs through our OEM and ODM services.
3. Q: What is your production capacity?
A: Our manufacturing facilities have the capability to produce up to 30,000 pressure sensor transmitters per month, ensuring that we can fulfill large-scale orders. However, it is advisable to contact our sales team in advance for smooth production and delivery scheduling.
4. Q: What's the typical delivery period?
A: Standard models typically have a delivery period of 5~8 working days, while customized products may vary.
5. Q: How are the products priced? Any discounts?
A: We offer competitive pricing with discounts available for bulk orders or long-term partnerships.
6. Q: What is the warranty of your products? And after-sales service?
A: Our products come with a 24-month warranty from shipment date, and our after-sales service ensures prompt responses within 24 hours along with remote instruction support via PC network.
