BT93420-II Temperature Indicator Transmitter
Introduction of temperature induicator transmitter:
BT93420-II submersible temperature transmitter is a type of temperature transmitter that is installed in a pipeline or vessel to measure the temperature of the medium. It typically measures the temperature by directly inserting into the interior of the pipeline or vessel and converts the temperature into a standardized electrical signal output. This type of temperature transmitter is suitable for industrial applications where real-time monitoring of the medium temperature is required, such as in chemical plants, pharmaceutical plants, food processing plants, and more. Submersible temperature transmitters are known for their high accuracy, strong reliability, and corrosion resistance to adapt to various harsh industrial environments.
Product Features of temperature induicator transmitter:
- Full stainless steel structure, good corrosion resistance
- Analog output and digital output are both available for selection
- Terminal box, 2088 LCD, or LED display are available for selection
Applications of temperature induicator transmitter:
- Monitor the temperature of generators, transformers, cables, and other critical equipment.
- Industrial Automation.
- Temperature measurement of various gases or liquids in pipelines in industries such as petroleum, chemical, power, and hydrology.
| Performance Parameters of temperature induicator transmitter |
| Measurement Range |
-55~400ºC |
| Accuracy @ 25ºC |
±0.5% (Typ.) ±1% (Max.) |
| Repeatability |
±0.03% (Typ.) ±0.05%FS (Max.) |
| Hysteresis |
±0.03% (Typ.) ±0.05%FS (Max.) |
| Long-Term Stability |
±0.2%F.S/year (Max.) |
| Operating Temperature |
-30~80ºC |
| Storage Temperature |
-40~100ºC |
| Housing Material |
1Cr18Ni9Ti |
| Diaphragm Material |
316L Stainless Steel |
| Insulation Resistance |
>=100MΩ@100VDC |
| Maximum temperature |
120% of the rated temperature range |
| Protection Rating |
IP65 |
| Weight |
~0.5Kg |
| Outline Construction of temperature induicator transmitter |
| Terminal Box |
|
| Order Guide |
| BT93420 |
Temperature Indicator Transmitter |
| |
Code |
Outline Construction |
| I |
Blue Terminal Box |
| II |
2088 housing |
| III |
2088+LED |
| IIIA |
3051+LED |
| |
Measurement Range |
-55~1200ºC |
| |
Code |
Power Supply |
| D1 |
24VDC |
| D2 |
Other |
| |
Code |
Output Signal |
| S1 |
4~20mADC |
S4 |
0~10mADC |
| S2 |
1~5VDC |
S5 |
0~20mADC |
| S3 |
0~5VDC |
S6 |
0~10VDC |
| |
Code |
Pressure Connection |
| J1 |
M27X2 Male |
| J2 |
Other |
| |
Code |
Insertion depth |
| L |
Actual insertion depth |
1. Q: What are the features of your pressure sensor transmitters?
A: High precision, durability, and excellent performance. Customization available.
2. Q: Can I customize special specifications?
A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service.
3. Q: What is your production capacity?
A: Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling.
4. Q: What's the typical delivery period?
A: 5~8 working day for standard models. Customized products may vary.
5. Q: How are the products priced? Any discounts?
A: Competitive pricing with discounts for bulk orders or long-term partners.
6. Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 24 months after shipment, and our after-sales will respond with your questions in 24hrs, remote instruction by PC network is always available.
